Zodiac Ranger Suction Cleaner: What's In The Box?

Hello and welcome ePoolSupply supporters! Today I will be going over what comes in the box for the Zodiac Ranger suction side pool cleaner. I will also give a brief description of the cleaner and add a picture so you know exactly which one I will be going over. At the bottom of the blog, there will be a YouTube video our pool professional has made to show you exactly what comes in the box. He will also give you some tips and tricks about the parts and the cleaner itself. Keep on reading to learn more!

About The Zodiac Ranger

The Zodiac Ranger suction side pool cleaner (W01698) offers dependable and affordable cleaning and will thoroughly clean your aboveground pool where it then removes dirt, debris, bugs, twigs, leaves, and even pebbles. This Zodiac suction-side pool cleaner comes pre-assembled in the box meaning it can be installed in just a few minutes, just attach the hose and start cleaning. This is specifically designed for vinyl pools.


  • Extra Large Wheel Deflector - Helps the Ranger from getting caught on steps, ladders, or corners so it can keep on cleaning your pool.
  • Quick Release Cassette and Diaphragm (inside) - The Ranger features one operational moving part. No gears, wheels, or flappers means simple operation and maintenance.
  • AG Disc - Allows the Ranger to glide effortlessly along the bottom of your pool, up the sides, and around steps, cleaning your whole pool.
  • Quiet Operation - Other cleaners make an annoying flapper or hammer noise. The Ranger was built to work quickly, effectively, and quietly.
Zodiac Ranger Pool Cleaner

What Comes In The Box

When opening the box, you will see the blue cleaner body. Next to the cleaner, there will also be the purple slotted disc (W70485). To install this on the cleaner, just stretch it over the foot pad into its groove. The next thing in the box is the large 16-inch wheel deflector (W46155). This helps to ensure that the cleaner does not stop or get stuck in any corners or other difficult spots to perform at optimal performance. The wheel deflector will go on the cassette pipe. Another thing that comes in the box is an accessory package. In this bag, you will find a 45-degree elbow (W70244), white connector (W33205), flow keeper valve (W60050), and valve cuff (W70264). The last thing you will receive in the box is a 12-pack of hoses (W38205)

In this video, we will show you what comes inside the box of a Zodiac Ranger Suction Side Pool Cleaner. We also describe some of the parts and how they work in your pool! If you have questions or need help with anything please contact us and we can help you to the best of our ability.
