Caretaker 99 High-Flow Bayonet Pop-Up Head (Light Gray) | 4-9-556

Name: Caretaker 99 High-Flow Bayonet Pop-Up Head (Light Gray) | 4-9-556
Brand: Caretaker
SKU: 4-9-556
Price: 62.95 USD
Availability: InStock

Caretaker | SKU: 4-9-556 | Barcode: 738919037496

$62⁹⁵ USD $94⁹⁵

Ships to

Product FAQs

What is included with 4-9-556?

One replacement head with the bonded, non-removable high-flow nozzle. Collar and tool sold separately.

Is the nozzle removable?

No. The high-flow nozzle supplied in this head is bonded in place. Do not remove it or substitute a standard nozzle insert.

Will it fit a different Caretaker connection?

Match the part number and installed fitting. Bayonet and legacy threaded heads use different attachments; do not select a head only by color or the age of the pool.

How is this head removed?

Stop the pump, prevent an automatic restart and let the head retract fully before using the proper head tool. Caretaker bayonet heads release counterclockwise and lock back into the collar clockwise. Follow the complete manufacturer procedure and do not force damaged components.

What should I check if cleaning is poor?

Use the owner manual to inspect the head, nozzle, collar and flow to the affected zone. A problem involving several heads may be elsewhere in the system. Have a qualified pool professional handle service beyond routine owner maintenance.

Where are the support documents?

The resources provide the head-and-collar guide, Caretaker owner manual and Jandy system overview. Use the valve-specific instructions for the valve actually installed on the pool.

Delivery and Shipping

FREE SHIPPING IN THE USA
WORLDWIDE SHIPPING AVAILABLE
30 DAY RETURNS

Resources & PDF Downloads

ePoolSupply Caretaker Head & Collar Installation Guide

Caretaker Owner's Manual - TL-1301 Rev-C

Jandy In-Floor Overview - 2022 Specialty Guide, pp. 20-23

Description

Caretaker | 4-9-556

Caretaker 99 High-Flow Bayonet Replacement Head - Light Gray

The Caretaker 4-9-556 is a Light Gray high-flow bayonet replacement head. Match the installed bayonet collar and retain the nozzle configuration specified for the cleaning location.

One replacement head with the bonded, non-removable high-flow nozzle. Collar and tool sold separately.

Match the fitting

Bayonet Caretaker connection. Check the actual collar and part number before ordering.

Water-driven head

The in-floor system raises and operates the head using water pressure; no separate electrical connection is required at the head.

Check fit before ordering

One replacement head with the bonded, non-removable high-flow nozzle. Collar and tool sold separately. Do not try to remove or exchange the bonded nozzle. Use a high-flow head only where the cleaning plan specifies it.

See Specifications, Resources & PDF Downloads and Product FAQs for identifiers, support and purchasing details.

Specifications

SKU

4-9-556
UPC or GTIN

738919037496
Product Type

Caretaker 99 High-Flow Bayonet Replacement Head - Light Gray
Size/Connection

Caretaker bayonet connection; replacement head only
Power Source

Hydraulic
