Pentair Tagelus Top Mount Sand Filter -- 24" (2" MPV) | SKU 145385

Pentair Tagelus TA60D Top Mount Sand Filter – 24″ (2″ MPV) | SKU 145385

Durable 24″ fiberglass-reinforced sand filter with 2″ multiport valve for residential pools.

Features

• One-piece fiberglass-reinforced tank offers exceptional strength and long-term durability.
• 2″ top-mounted six-position Hi-Flow™ multiport valve simplifies service and enhances flow.
• 3.1 sq. ft. filtration area and 24″ diameter tank support up to ~60 GPM throughput.
• Combination water and sand drain design eases winterizing and maintenance.
• Special diffuser and lateral system maintain a uniform sand bed for consistent filtration and longer cycles between backwashes.

Description

The Pentair Tagelus TA60D Top Mount Sand Filter delivers premium-level filtration performance for residential in-ground pools. Featuring a robust one-piece fiberglass tank and a full-sized 2″ multiport valve, it accommodates higher flow systems and simplifies service routines. The internal diffuser and lateral architecture ensure efficient sand utilization and extended filter runs, while the service-friendly drain speeds cleanup and winter shutdown. Ideal for pool owners demanding reliable, high-capacity filtration with minimal maintenance.

Pro Tip

While installing, check your sand media and consider upgrading to higher-performance glass or zeolite media. Also inspect the internal laterals and standpipe — these wear over time and can save significant service cost later.

Installation Tips

Shut off power to the pool pump and relieve system pressure before installing. Ensure that your plumbing matches the 2″ valve ports, and that there is adequate clearance above the tank for valve removal. Add media into the tank under water to protect laterals, and run initial backwash after fill-up before returning to normal service.
