Caretaker 99 Threaded Pop-Up Head (Charcoal Gray) | 3-9-513

Caretaker 3-9-513: Threaded Pop-Up Head in Charcoal Gray

The Caretaker 3-9-513 is a Charcoal Gray threaded pop-up head for legacy Caretaker threaded floor fittings. Choose this replacement when your existing collar is in good condition and matches the head connection. During a cleaning cycle, water from the in-floor system raises the head and directs a jet across the pool surface to move debris along the planned cleaning path.

Nozzle insert required: This listing does not include a nozzle insert. Choose the correct insert for the head location; color alone does not determine the nozzle size.

Product Details

Check Fit Before Ordering

• Match part number 3-9-513, the Charcoal Gray color and the connection style to your existing installation.
• Threaded heads and bayonet heads use different locking connections. Confirm the fitting itself rather than relying only on the age of the pool.
• Match the nozzle selection to your pool's cleaning plan or the correctly sized insert in the head being replaced.

Recommended Tool and Head Service

For head removal and installation, we recommend the HammerTech Solutions All Metal Caretaker Tool | HTS-Caretaker. It can be used by hand or attached to a standard pool pole, making it useful for reaching submerged heads. The tool is sold separately.

Shut off the pump and prevent an automatic restart before servicing. Make sure the head is fully down and the tool is engaged. Legacy threaded heads release clockwise; do not use the bayonet removal direction. Inspect the head, collar and nozzle for trapped debris. Do not force a stuck head or damaged collar.

Common Questions

Does this include a nozzle?

Nozzle insert sold separately; select the size specified for this location.

Will this fit every Caretaker system?

No. Match the fitting style, part number and nozzle configuration. Older threaded heads and bayonet heads are not interchangeable.

Why is my head not cleaning properly?

A blocked nozzle, debris in the collar or inadequate flow to the cleaning zone can affect operation. Check the owner's manual before assuming the head needs replacement; a problem affecting several heads may be elsewhere in the system.

Select the Required Nozzle Insert

Choose the insert called for by your cleaning plan. These inserts are sold separately; the high-flow configuration uses a different, factory-installed nozzle.

• Mini | 1-9-458
• Step & Bench | 1-9-459
• Flow Adjust | 1-9-455
• Standard | 1-9-461
• Flow Plus | 1-9-456

Support Documents

The owner's manual provides general system operation and troubleshooting. Its quarter-turn head illustrations show bayonet heads; use the clockwise removal direction for the older threaded fitting described above.

See the PDF Downloads section for the documents listed below.

• Caretaker Owner's Manual — Operation & Troubleshooting
• Jandy In-Floor Overview — Pages 20–23
