Pentair FullFloXF 2-Way Check Valve CPVC 2.5″ / 3″ | 263060

Pentair FullFloXF 2-Way Check Valve CPVC 2.5″ / 3″ – SKU 263060

Optimize flow and protect your pool equipment with the Pentair FullFloXF 2-Way Check Valve (SKU 263060). High-flow, CPVC body, made for 2.5″/3″ plumbing.

Features

• Industry-leading flow capacity up to 180 GPM with minimal head loss.
• High-temperature CPVC construction for superior heat and chemical resistance.
• Slip-socket design supports 2½″ nominal / 3″ O.D. plumbing for versatile installation.
• Rated to 50 PSI working pressure and certified to NSF/ANSI 50 aquatic safety standards.
• Low-tension spring check mechanism prevents backflow and protects connected equipment.

Description

Built for durability and high-performance plumbing systems, the Pentair FullFloXF 2-Way Check Valve (SKU 263060) features a CPVC body capable of withstanding the harsh chemical and thermal conditions typical of pool environments. Its design ensures a large internal flow area to minimise head loss, while the check-valve mechanism prevents unwanted reverse flow, protecting pumps, heaters, and filters from damage. The slip socket design accommodates either 2½″ or 3″ pipe, offering installation flexibility. Certified to NSF/ANSI 50, it meets rigorous standards for use in aquatic systems.

Pro Tip

For optimal performance, pair this check valve with a compatible actuator or automated diverter—especially in high-flow systems—to ensure reliable shut-off and minimal back-flow.

Related Parts

• Pentair Rebuild Kit | SKU 263042Z

Installation Tips

Ensure plumbing is depressurized before installation. Align the flow-direction arrow on the valve body with system flow. Use appropriate primer and solvent cement for CPVC/PVC bonding. Verify compatibility with upstream equipment and confirm valve orientation allows full closure without interference.
