Pentair EC-LA01N is the Universal Booster pressure-side cleaner booster pump. Choose it for a compatible cleaner that requires a separate pressure booster.

What makes this configuration different

EC-LA01N supplies pressurized water to a compatible pressure-side cleaner. Pentair rates it at 50 psi at 12 GPM and includes the hose and adapters. It depends on water supplied by the filtration system and must be coordinated with the circulation pump; it is not a substitute for that pump.

Coordinate cleaner and filter-pump operation

The cleaner booster must have the water supply described in its installation guide. Plan the control schedule or interlock so the booster cannot run without the filter pump providing adequate flow. Confirm the cleaner’s required pressure and plumbing arrangement before replacing an existing booster.

Installation and electrical planning

Verify the 115/230V supply requirements against the motor label and connection diagram. Provide the mounting, wiring, grounding, bonding and circuit protection required by the guide. Confirm applicable installation-location requirements before purchase.

Service and replacement planning

Keep the strainer and circulation path maintained where applicable, inspect for leaks, and follow the manual’s priming and shutdown procedures. Stop the equipment and relieve system pressure before opening pressurized components. Match replacement parts to the full model and production revision; visually similar pumps may use different drives, motors or hydraulic components.

Specifications

Frequently asked questions

Will this replace any pump with the same horsepower?

No. Compare the performance curve, electrical requirements, plumbing and physical fit. Match the full model rather than horsepower alone.

Is the electrical supply interchangeable?

This model’s listed supply is 115/230V. Have the installer verify the unit label and configure any permitted voltage selection exactly as instructed.

Can it run when the filter pump is off?

No. The booster requires the filtration system to supply water. Follow Pentair’s coordinated-operation requirements.

Which manual should I use?

Use the manufacturer guide for the exact pump family and production revision. Retain the unit’s data plate information when ordering service parts.
