Pleatco ULTRA-A10-PAK4 + Aladdin O-524-BAGGED O-Ring Bundle | ULTRA-A10-PAK4+O-524-BAGGED

Pleatco ULTRA-A10-PAK4 + Jandy CL/CV 580 Tank O-Ring Bundle | ULTRA-A10-PAK4+O-524-BAGGED

Complete service bundle for Jandy CL/CV 580 cartridge filters: Pleatco ULTRA-A10-PAK4 4-pack cartridges plus Jandy R0357800 / Aladdin O-524 tank O-ring to restore flow and seal at the clamp.

Features

• Fits Jandy CL580 / CV580 cartridge filter systems (PJAN145 footprint)
• ULTRA-A10-PAK4 cartridge set: PurePleat, point-bonded fabric, and Free-Flow core
• Each cartridge approx. 7⅛" diameter × 32⅞" length; 3" open top and bottom
• Replaces OEM A0104000 / PJAN145 cartridges and equivalents
• O-524 tank O-ring replaces Jandy R0357800 (CL, CV, DEL, DEV series lid seal)
• O-ring dimensions around 21-15/16" ID × 23" OD × 9/16" cross-section for proper clamp sealing

Description

This bundle tackles both performance and sealing on Jandy CL/CV 580 filters. The Pleatco ULTRA-A10-PAK4 cartridge pack is a direct upgrade for the OEM PJAN145 / A0104000 elements, with UlTRA media and a Free-Flow core designed to maintain flow and extend cleaning intervals. The Aladdin O-524 tank O-ring replaces Jandy R0357800, which seals the lid and body under the clamp band. Swapping media and gasket together is the straightforward way to lower pressure, clear up flow issues, and stop nuisance leaks at the band.

Pro Tip

Change all four cartridges at the same time—never mix new and old elements in a CL/CV 580 tank. Before installing the new O-ring, clean the groove and tank lips, then apply a thin film of pool-safe silicone or PTFE lube. Seat the band evenly, purge air on restart, and watch the clamp area for any weeping as the filter comes up to pressure.

Related Parts

• Pleatco PJAN145-PAK4 Standard Cartridge Set | PJAN145-PAK4
• Jandy R0357800 Tank O-Ring Only | O-524-BAGGED
• Magic Lube® PTFE O-Ring Lubricant | 630

Technical Specifications
